Smart Foam Underlay
Passive protection built into the floor. Kradal™ Smart Foam Underlay is a bespoke closed-cell flexible polyurethane foam, specifically designed to minimise injuries from falls — firm to walk on yet impact absorbent.
Key Features
59% reduction in fall injury risk
46% impact force reduction
5-Star AAAC acoustic rating
Bfl-s1 fire classification
0.0mm thickness loss after 1000 impacts
Kradal™ Smart Foam Underlay is installed beneath sheet vinyl or linoleum on a prepared concrete subfloor. Once installed, it provides continuous, maintenance-free fall injury protection 24 hours a day, 7 days a week — without changing how people move or work.
59% Injury Reduction
Clinically proven in a 3-year peer-reviewed study at Karlstad University, published in BMJ Injury Prevention.
5 Star Acoustics
AAAC 5-Star rating. L'nT,w of 42 — an 18 dB improvement over bare concrete. Exceeds BCA 2019 requirements.
Stable Underfoot
Only 4.2mm vertical deformation on impact. Safe for wheelchairs, walkers, trolleys, and medical equipment.
Fire Rated Bfl-s1
Approved for sleeping and non-sleeping occupancy, in both sprinkler and non-sprinkler protected premises.
Wet Area Suitable
Closed-cell construction — non-water absorbing. Install in bathrooms, showers, hallways, and bedrooms.
100% Recyclable
Manufactured with 10% renewable content. Anti-fungal tested (AATCC 30 — Pass). Anti-bacterial protection.
.jpeg)
Kradal™ was originally developed as an alternative to hip protectors. The Aged Care Research Group at Otago University advised that while hip protectors worked in testing, the compliance burden made them ineffective in practice. Kradal™ embeds the protection directly into the floor — no compliance required, protecting all parts of the body, not just the hips.
Applications
Kradal Smart Foam Underlay is recommended for use with vinyl or linoleum sheet (nominal thickness 2mm) in all areas of aged care facilities, including wet areas. It is also suitable for childcare centres, hospitals, gymnasiums, and the private homes of elderly people. The subfloor should be prepared appropriately and suitable adhesives used. Installation should be completed by experienced flooring technicians.
Frequently Asked Questions
Can Kradal™ be installed in bathrooms?
Yes, Kradal™ is suitable for wet areas, including showers.
Can Kradal™ be installed over existing tiles?
Yes, using a special process, Kradal™ can be installed over tile. Contact us for further information.
What types of vinyl work with Kradal™?
Most two millimetre thick vinyl sheets from quality manufacturers are applicable. Please contact us for clarification before installation.
Can I install click vinyl over Kradal™?
No, only vinyl sheet may be installed. Please consult our installation brochure for more information.
Is Kradal™ difficult to install?
No, the installation of Kradal™ is the same as normal vinyl except for the additional step of adding the underlay. Technicians must ensure perfect weld quality between vinyl sheet joins.
